Pneucon valves are designed and manufactured as per ASME B16.34/ API 6D/ BS EN 17292.
These Standards Cover Pressure – Temperature ratings, minimum shell thickness, bore diameter for each size/class.
Castings inspection as per MSS-SP 53, 54, 55, 59, 93 & 94
Actuator mounting pad on the valve is as per ISO 5211.
Other applicable standards
Face to Face: ASME B 16.10
Flange Dimension: ASME B 16.5
Butt Welded: ASME B 16.25 /
Valve Ends: B31.3 / B31.4 / API 6D
Pressure Tests : API 598 / BS EN 12266 – I / API 6D.
